QCT QuantaGrid D53XQ-2U

Scale Ahead for the Workload of Tomorrow

• Ultimate resilience and scalability with up to 10x PCIe 4.0 expansions
• Optimized for AI acceleration: Support up to 2x dual-width accelerators in 2U system
• Support All 24x NVMe flash drives as hot tier storage, targeting HPC and enterprise workloads.

Ultimate Compute Performance and Security Architecture

• 3rd Gen Intel® Xeon Scalable Processor Ice Lake based dual socket platform.
• Up to 3x UPI at 11.2 GT/sec CPU interconnect speed.
• Advance system cooling support up to 270W CPU TDP per socket
• Memory capacity up to 8TB with 8 channel DDR4 memory and 12TB with 2nd Gen Intel® Optane™ PMem 200 Series Barlow Pass.

Scalability, Flexibility, Capability, All in 2U

• Built-in AI acceleration: support up to 2x dual-width accelerators in 2U systems
• Flexible SKU options from 12x 3.5” drive to 24x 2.5” /U.2 drive with PCIe Gen 4
• Optional rear NVMe as booting device  (Intel VMD supported), or high speed NIC with optional HHHL slots
• 24x PCIe Gen 4 NVMe drives. For high performance hot tier storage, HPC and enterprise workloads

Enhanced Security

• Chassis intrusion triggered when top cover removed while AC/DC on, to alter and log any possible breach to your QCT servers.

Quick Deployment with Great Serviceability

• Tool-less, hot-swap designs for drive trays, riser brackets and fan modules.
• Auto back-up BMC event logs in microSD without opening chassis.
• Easy service with OCP3.0 pull-tab & ejector without opening chassis.

Easy Management

• Secure and dynamic data administration of data center resources with Orqestra (QCT System Manager).
• Monitor up to 5000 devices per Orqestra module.
