QCT QuantaGrid D53X-1U

Balanced architecture with built-in acceleration and advanced security

• 3rd Gen Intel® Xeon Scalable processor Ice Lake empowered
• PCIe Gen 4 platform ready
• Support up to 200GbE with PCIe x16 Networking bandwidth
• Upgrade data protection with Intel SGX, Intel® Crypto Acceleration, and PFR (optional)

Ultimate Compute Performance and Security Architecture

• 3rd Gen Intel Xeon Scalable Processor Ice Lake based dual socket platform.
• Up to 3x UPI at 11.2 GT/sec CPU interconnect speed.
• Advance system cooling support up to 270W CPU TDP per socket
• Memory capacity up to 8TB with 8 channel DDR4 memory and 12TB with 2nd Gen Intel® Optane™ PMem 200 Series Barlow Pass.
• Up to 3x Single Width Tesla T4 GPU in 1U system.
• System optimized for cloud, enterprise, AI, HPC, network, security and IoT workloads.

Flexible and Scalable Configurations

• Industry most expansions in 1U system with up to 5x PCIe Gen 4 slots, supporting 200GbE networking bandwidth in x16 PCIe Gen 4 slots.
• Flexible I/O options with a variety of SAS mezzanine and OCP mezzanine options for diverse configurations.
• Vast variety of storage configurations, supporting All Flash, Tiered and Hybrid SKUs.
• 2x onboard PCIe M.2 2230 slot.

Enhanced Security

• Chassis intrusion triggered when top cover removed while AC/DC on, to alter and log any possible breach to your QCT servers.

Quick Deployment with Great Serviceability

• Tool-less, hot-swap designs for drive trays, riser brackets and fan modules.
• Auto back-up BMC event logs in MicroSD without opening chassis.
• Easy service with OCP3.0 pull-tab & ejector without opening chassis.

Easy Management with Orqestra

• Secure and dynamic data administration of data center resources with Orqestra
• Monitor up to 5000 devices per QST (QCT Service Tool).
